| Double-head Water Slot Milling Machine |
| |
|
| Product detail information: |
|
CLXCZ2A Double-head Water Slot Milling Machine
Equipment features
● Milling all kinds of water slots and air pressure balance grooves.
● Special feeding system, high milling quality, need no special maintenance.
● Water slot milling length adjustable within 60mm.
● Two three-axis milling heads layout along the machine guide .
● One time clamp, two end water slots processing.
● High efficiency, suitable for mass production.
Main technical parameter
●Air pressure 0.5~0.8Mpa
●Air consumption 50L/min
●Power supply 220V 50Hz
●Input power 2.28kW
●Cutter diameter φ5 φ8
●Slot depth 30mm
●Slot length 0~100mm
●Contour dimension 3800×1200×1800mm
●Weight 900kg
|
|
|
|
|
|
|
|
|
